Lenovo ES-511 RS-232/422/485 Serial Server

Lenovo ES-511 RS-232/422/485 Serial Server
Lenovo ES-511 RS-232/422/485 Serial Server
Lenovo ES-511 RS-232/422/485 Serial Server
Lenovo ES-511 RS-232/422/485 Serial Server
Lenovo ES-511 RS-232/422/485 Serial Server
Lenovo ES-511 RS-232/422/485 Serial Server
Lenovo ES-511 RS-232/422/485 Serial Server
Lenovo ES-511 RS-232/422/485 Serial Server
Lenovo ES-511 RS-232/422/485 Serial Server
Lenovo ES-511 RS-232/422/485 Serial Server
Lenovo ES-511 RS-232/422/485 Serial Server
Lenovo ES-511 RS-232/422/485 Serial Server
secure_payment

Secure Payment

secure_payment

Free UK Shipping

secure_payment

Easy Return

SKU: 4Z10A39514

£79.99inc. VAT
klarna_logoPay later with Klarna
pay_in_3Pay in 3 with 0% Interest
Highlights
  • Power Consumption: 60 mA
  • Wiring Technology: 10/100/1000Base-T(X)
  • Baud Rate: 1000 Kbit/s
  • Yello Colour
  • 1 Year Warranty
  • 4Z10A39514
  • Condition: New
Explore the Lenovo Store
Product Description

Ethernet to Serial Device with 1 Port software selectable as RS232, RS422/485 Full duplex or RS422 Half duplex. ES-511 has removable Screw Terminals Blocks for easy wiring, a slim 'end on' case and integral DIN rail mount. Our Industrial Ethernet to Serial has an operating temperature range of -30 to +80 degrees Celsius and with +5VDC to +30VDC Dual input reverse polarity protected power supply making it perfect for industrial applications. Data transfer rates up to 1,000,000 baud, coupled with 1Mbit/s line drivers deliver uncompromising performance. Our Industrial ES range provides simple instant networked serial ports in demanding environments. Serial Port Tunneling allows serial cable replacement over any distance, no software required. Suitable to be wired into existing power and network infrastructure or can be used with our PW-600 power supply.

Condition
ConditionNew
Product Identifiers
SKU4Z10A39514
MPN4Z10A39514
EAN0887770889789
TypeSERIAL SERVER
BrandLENOVO
Model4Z10A39514
General
Warranty1 Year
ColourYello
Weight108 g
Dimensions(WxDxH) 96.3 x 101 x 25 mm
Key Specifications
Key Specification 1Serial Interface Type: RS-232/422/485
Key Specification 2Ethernet LAN Transfer Speed: 10,100 Mbps
